Cell Type: polycrystalline
Number of cells:60
Module efficiency:≥16%
Maximum system voltage:1000V DC
Maximum fuse rated current:15A
Frame:Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP65/IP67
Connectors: MC4 compatible
| Product Code | LK-60M-260W260W | LK-60M-265W265W | LK-60M-270W270W | LK-60M-280W280W | LK-60M-290W290W |
|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 260 | 265 | 270 | 280 | 290 |
| Open Circuit Voltage(VOC/v) Voc/v | 37.4 | 37.7 | 38.0 | 38.6 | 38.7 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 30.3 | 30.6 | 30.9 | 31.5 | 31.6 |
| Short Circuit Current(Isc/A)Isc/A | 9.15 | 9.21 | 9.29 | 9.42 | 9.93 |
| Maximum Power Current(imp/A)imp/A | 8.59 | 8.67 | 8.74 | 8.89 | 9.18 |
| Dimension(mm)Dim.(mm) | 1640*992*35 | ||||
| Weight(kg)Weight(kg) | 18 | ||||
| Power Tolerance | ±3% tolerance | ||||
| α ISC | -0.05%/°C | ||||
| β Voc | -0.29%/°C | ||||
| γ Pmp | -0.4%/°C | ||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | ||||
| Remarks: | model is LK- 60M- () | ||||
