Cell Type: Monocrystalline
Number of cells:36
Module efficiency:≥15.1%
Maximum system voltage:1000V DC
Maximum fuse rated current:15A
Frame: Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP65/IP67
Connectors: MC4 compatible
| Product Code | LK-36M-150W150W | LK-36M-160W160W | LK-36M-170W170W | LK-36M-180W180W | LK-36M-190W190W | LK-36M-200W200W | LK-36M-210W210W |
|---|---|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 150 | 160 | 170 | 180 | 190 | 200 | 210 |
| Open Circuit Voltage(VOC/v) Voc/v | 21.8 | 22.3 | 22.8 | 23.5 | 23.8 | 24.1 | 23.4 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 18.0 | 18.2 | 18.5 | 19.0 | 19.4 | 19.8 | 20.20 |
| Short Circuit Current(Isc/A)Isc/A | 9.18 | 9.57 | 9.75 | 9.82 | 10.17 | 10.51 | 11.36 |
| Maximum Power Current(imp/A)imp/A | 8.33 | 8.79 | 9.19 | 9.47 | 9.79 | 10.1 | 10.4 |
| Dimension(mm)Dim.(mm) | 1480*670*35 | ||||||
| Weight(kg)Weight(kg) | 11 | ||||||
| Power Tolerance | ±3% tolerance | ||||||
| α ISC | -0.05%/°C | ||||||
| β Voc | -0.29%/°C | ||||||
| γ Pmp | -0.4%/°C | ||||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | ||||||
| Remarks: | model is LK- 36M- () | ||||||
