Cell Type: Monocrystalline
Number of cells:72
Module efficiency:≥19.6%
Maximum system voltage:1500V DC
Maximum fuse rated current:20A
Frame:Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP65/IP67
Connectors: MC4 compatible
Cable length: customizable
| Product Code | LK-72M-420W420W | LK-72M-425W425W | LK-72M-430W430W | LK-72M-435W435W | LK-72M-440W440W | LK-72M-445W445W | LK-72M-450W450W |
|---|---|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 420 | 425 | 430 | 435 | 440 | 445 | 450 |
| Open Circuit Voltage(VOC/v) Voc/v | 48.3 | 48.5 | 48.7 | 48.8 | 49.0 | 49.3 | 49.5 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 40.9 | 41.3 | 41.6 | 41.8 | 42.3 | 42.6 | 42.7 |
| Short Circuit Current(Isc/A)Isc/A | 11.75 | 11.83 | 11.94 | 12.04 | 12.13 | 12.19 | 12.29 |
| Maximum Power Current(imp/A)imp/A | 10.27 | 10.28 | 10.33 | 10.40 | 10.41 | 10.46 | 10.54 |
| Dimension(mm)Dim.(mm) | 2060*1038*35 | ||||||
| Weight(kg)Weight(kg) | 24 | ||||||
| Power tolerance | ±3% tolerance | ||||||
| α ISC | -0.05%/°C | ||||||
| β Voc | -0.29%/°C | ||||||
| γ Pmp | -0.4%/°C | ||||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | ||||||
| Remarks: | model is LK- 72M- () | ||||||
