Cell Type: 182mm Monocrystalline
Number of cells:72
Module efficiency:≥20.8%
Maximum system voltage:1500V DC
Maximum fuse rated current:25A
Frame: Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP68
Connectors: MC4 compatible
| Product Code | LK-72M-530W530W | LK-72M-535W535W | LK-72M-540W540W | LK-72M-545W545W | LK-72M-550W550W | LK-72M-555W555W |
|---|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 530 | 535 | 540 | 545 | 550 | 555 |
| Open Circuit Voltage(VOC/v) Voc/v | 49.46 | 49.72 | 49.80 | 49.89 | 50.13 | 50.23 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 41.13 | 41.36 | 41.55 | 41.77 | 41.95 | 42.06 |
| Short Circuit Current(Isc/A)Isc/A | 13.66 | 13.72 | 13.78 | 13.84 | 13.90 | 14.08 |
| Maximum Power Current(imp/A)imp/A | 12.89 | 12.94 | 13.00 | 13.05 | 13.11 | 13.20 |
| Dimension(mm)Dim.(mm) | 2250*1134*35 | |||||
| Weight(kg)Weight(kg) | 26 | |||||
| Power tolerance | ±3% tolerance | |||||
| α ISC | -0.05%/°C | |||||
| β Voc | -0.29%/°C | |||||
| γ Pmp | -0.4%/°C | |||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | |||||
| Remarks: | model is LK- 72M- () | |||||
