Cell Type: 182mm Monocrystalline
Number of cells:54
Module efficiency:≥20.2%
Maximum system voltage:1500V DC
Maximum fuse rated current:25A
Frame: Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP68
Connectors: MC4 compatible
| Product Code | LK-54M-390W390W | LK-54M-395W395W | LK-54M-400W400W | LK-54M-405W405W | LK-54M-410W410W | LK-54M-415W415W |
|---|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 390 | 395 | 400 | 405 | 410 | 415 |
| Open Circuit Voltage(VOC/v) Voc/v | 36.52 | 36.76 | 36.95 | 37.18 | 37.43 | 37.68 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 30.44 | 30.61 | 30.83 | 31.08 | 31.29 | 31.51 |
| Short Circuit Current(Isc/A)Isc/A | 13.63 | 13.71 | 13.80 | 13.87 | 13.94 | 14.02 |
| Maximum Power Current(imp/A)imp/A | 12.81 | 12.90 | 12.97 | 13.03 | 13.10 | 13.17 |
| Dimension(mm)Dim.(mm) | 1700*1134*35 | |||||
| Weight(kg)Weight(kg) | 19 | |||||
| Power tolerance | ±3% tolerance | |||||
| α ISC | -0.05%/°C | |||||
| β Voc | -0.29%/°C | |||||
| γ Pmp | -0.4%/°C | |||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | |||||
| Remarks: | model is LK- 54M- () | |||||
