Cell Type: Monocrystalline
Number of cells:60
Module efficiency:≥19.2%
Maximum system voltage:1500V DC
Maximum fuse rated current:20A
Frame: Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP65/IP67
Connectors: MC4 compatible
| Product Code | LK-60M-345W345W | LK-60M-350W350W | LK-60M-360W360W | LK-60M-370W370W | LK-60M-380W380W |
|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 345 | 350 | 360 | 370 | 380 |
| Open Circuit Voltage(VOC/v) Voc/v | 39.9 | 40.3 | 40.6 | 41.0 | 41.1 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 33.5 | 34.1 | 34.7 | 35.4 | 35.5 |
| Short Circuit Current(Isc/A)Isc/A | 11.68 | 11.75 | 11.98 | 12.20 | 12.49 |
| Maximum Power Current(imp/A)imp/A | 10.30 | 10.27 | 10.36 | 10.45 | 10.70 |
| Dimension(mm)Dim.(mm) | 1730*1038*35 | ||||
| Weight(kg)Weight(kg) | 20 | ||||
| Power Tolerance | ±3% tolerance | ||||
| α ISC | -0.05%/°C | ||||
| β Voc | -0.29%/°C | ||||
| γ Pmp | -0.4%/°C | ||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | ||||
| Remarks: | model is LK- 60M- () | ||||
