Cell Type: 182mm Monocrystalline
Number of cells:66
Module efficiency:≥20.5%
Maximum system voltage:1500V DC
Maximum fuse rated current:25A
Frame: Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP68
Connectors: MC4 compatible
| Product Code | LK-66M-480W480W | LK-66M-485W485W | LK-66M-490W490W | LK-66M-495W495W | LK-66M-500W500W |
|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 480 | 485 | 490 | 495 | 500 |
| Open Circuit Voltage(VOC/v) Voc/v | 44.97 | 45.23 | 45.47 | 45.72 | 45.83 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 37.50 | 37.68 | 37.89 | 38.10 | 38.28 |
| Short Circuit Current(Isc/A)Isc/A | 13.64 | 13.70 | 13.76 | 13.81 | 13.87 |
| Maximum Power Current(imp/A)imp/A | 12.80 | 12.87 | 12.93 | 12.99 | 13.06 |
| Dimension(mm)Dim.(mm) | 2060*1134*35 | ||||
| Weight(kg)Weight(kg) | 24 | ||||
| Power tolerance | ±3% tolerance | ||||
| α ISC | -0.05%/°C | ||||
| β Voc | -0.29%/°C | ||||
| γ Pmp | -0.4%/°C | ||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | ||||
| Remarks: | model is LK- 66M- () | ||||
