Cell Type: 182mm Monocrystalline
Number of cells:48
Module efficiency:≥19.9%
Maximum system voltage:1500V DC
Maximum fuse rated current:25A
Frame: Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP68
Connectors: MC4 compatible
| Product Code | LK-48M-340W340W | LK-48M-345W345W | LK-48M-350W350W | LK-48M-355W355W | LK-48M-360W360W | LK-48M-365W365W |
|---|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 340 | 345 | 350 | 355 | 360 | 365 |
| Open Circuit Voltage(VOC/v) Voc/v | 32.46 | 32.59 | 32.74 | 32.83 | 32.93 | 33.02 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 27.06 | 27.21 | 27.40 | 27.65 | 27.74 | 27.84 |
| Short Circuit Current(Isc/A)Isc/A | 13.37 | 13.51 | 13.63 | 13.77 | 13.91 | 14.07 |
| Maximum Power Current(imp/A)imp/A | 12.57 | 12.68 | 12.77 | 12.84 | 12.98 | 13.11 |
| Dimension(mm)Dim.(mm) | 1510*1134*35 | |||||
| Weight(kg)Weight(kg) | 17 | |||||
| Power tolerance | ±3% tolerance | |||||
| α ISC | -0.05%/°C | |||||
| β Voc | -0.29%/°C | |||||
| γ Pmp | -0.4%/°C | |||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | |||||
| Remarks: | model is LK- 48M- () | |||||
