Cell Type: 182mm Monocrystalline
Number of cells:60
Module efficiency:≥20.4%
Maximum system voltage:1500V DC
Maximum fuse rated current:25A
Frame: Anodized aluminum alloy
Glass: 3.2mm tempered glass
Junction box: IP68
Connectors: MC4 compatible
| Product Code | LK-60M-435W435W | LK-60M-440W440W | LK-60M-445W445W | LK-60M-450W450W | LK-60M-455W455W | LK-60M-460W460W |
|---|---|---|---|---|---|---|
| Rated Maximum Power at STC(w) STC(w) | 435 | 440 | 445 | 450 | 455 | 460 |
| Open Circuit Voltage(VOC/v) Voc/v | 40.60 | 40.86 | 41.07 | 41.33 | 41.60 | 41.81 |
| Maximum Power Voltage(Vmp/V) Vmp/V | 33.83 | 34.06 | 34.27 | 34.52 | 34.77 | 34.95 |
| Short Circuit Current(Isc/A)Isc/A | 13.68 | 13.74 | 13.82 | 13.88 | 13.93 | 14.01 |
| Maximum Power Current(imp/A)imp/A | 12.86 | 12.92 | 12.99 | 13.04 | 13.09 | 13.16 |
| Dimension(mm)Dim.(mm) | 1880*1134*35 | |||||
| Weight(kg)Weight(kg) | 21 | |||||
| Power tolerance | ±3% tolerance | |||||
| α ISC | -0.05%/°C | |||||
| β Voc | -0.29%/°C | |||||
| γ Pmp | -0.4%/°C | |||||
| STC (Standard test conditions) | AM1.5, 1000W/m², 25±2°C | |||||
| Remarks: | model is LK- 60M- () | |||||
